Full Description
Wireless Monitoring System
To start monitor your live performance in real time with the Shure SE112 headphones simply connect your desired audio source to the XLR/Line level connections on the front of the transmitter and set the transmission frequency to match with the receiver. Then plug in the SE112 headphones and use the on board controls on the bodypack to fine tweak until you are happy with the volume level.
Shure SE112 Headphones
The Shure SE112 headphones are a premium set of in-ear headphones which incorporate a sound cancelling design to reduce unwanted noise from the surrounding environment making them perfect for live performance. Additionally the soft silicone buds adapt to suit a range of ear sizes providing a comfortable and secure fit.
Features
- Robust and Reliable Wireless Monitoring System
- Built-In Headphone and Audio Limiter
- Front Mounted Antenna
- 2 x Mic/Line Input Channels for Mix Control
- Up to 100m Operating Distance
- Volume Control on Bodypack Receiver
- Rack Mountable (1/2 Rack Space)
- High Performance SE112 In-Ear Headphones
- Selectable Frequency Bandwidth (600-630 MHz)
Specifications
General
- Transmitter Inputs: 2 x XLR / 6.3mm Jack Combo (Mic/Line Level)
- Transmitter Output: 2 x XLR Split Outputs
- Frequency Response: 30 Hz - 12 kHz
- Transmitting Frequency: 600-630 MHz (Selectable)
- RF Output Power: 10 - 30 mW
- Operating Distance: Up to 100m
- Harmonic Distortion: 1.5
- S/N Ratio: 80 dB (A)
- Listening Mode: Mono
- Compatible Systems (Per Band): 4
- Wired Body Pack Option: Yes
- Personal Mix Control: On Transmitter
- Remoteable Transmitter: No
- Battery Life (Wired): 6 Hours
- Battery Life (Wireless): 4 Hours
EP2T TransMixer
- Modulation Limiter: Internal Peak Limiter (>10:1 Hard Knee Compression)
- Antenna: 1/4 Wavelength, Semi-Rigid, PCB Mount
- Connector Type: XLR / 1/4" Jack Combo
- Nominal Input Level: - 25 dBu (50 Volume)
- Maximum Input Level: - 5 dBu (50 Volume)
- Current (Max): 170 mA
- Height: 8.6"
- Width: 5.6"
- Depth: 1.7"
- Weight: 370g
P2R Receiver
- RF Sensitivity: 109 dBm
- Squelch Threshold: 102 dBm
- Antenna: Attached Whip
- Audio Input Connector: 1/4" Jack (Mono)
- Impedance: 1 M Ohm
- Input Level (Max): LO - 0 dBu / HI - 10 dBu
- Frequency Response: 30 Hz to 20 kHz (Earphone Dependent)
- Power Requirements: 9 V Battery
- Audio Output Connector: 1/8" Jack
- Minimum Load Impedance: 8 Ohms
- Height: 4.809"
- Width: 2.875"
- Depth: 1.251"
- Weight: 100g
SE112 Earphones
- Earphone Type: In-ear
- Frequency Response: 25 Hz - 17.5 kHz
- Sensitivity: 108 dB (1 kHz)
- Impedance: 16 Ohms
- Input Connector: 3.5mm
- Finish: Grey
- Cable Length: 127 cm
